Contour Logos and Logo Boxes
A contour logo or logo box is a three-dimensional sign designed to showcase your brand’s logo or emblem. Unlike traditional flat signs, this type of signage can be contoured to the shape of the logo itself, or as a basic shape, like a circle or square, that can also include text and other information.
A contour logo or logo box is a three-dimensional sign designed to showcase your brand’s logo or emblem. Unlike traditional flat signs, this type of signage can be contoured to the shape of the logo itself, or as a basic shape, like a circle or square, that can also include text and other information.
If your client is looking for a unique way to incorporate their logo into their signage, a contour logo box could be a great option. A contour logo, also known as a logo box or cloud logo, can increase brand awareness, reinforce brand recognition, and communicate what the product is.
Channel letter contour logos are often paired with channel letters, and it can even display a catchy tagline. Logo boxes can be contoured to any shape and are generally illuminated by LED lighting, giving your customer more options, possibilities, and impact.
Benefits of Using Contour Logos with Channel Letter Signs:
-
- Brand Awareness: Combining your logo with channel letter signs increases brand visibility. Passersby instantly recognize your business, reinforcing brand recall.
- Eye-Catching Design: Contour logos add depth and dimension, making your sign stand out. The play of light and shadow draws attention.
- Locator Function: Logo boxes serve as a visual locator for your storefront. Customers easily spot your business even from a distance.
- Marketing Impact: A well-designed logo box becomes part of your marketing campaign. It communicates professionalism and quality.
- Customization: Logo boxes can be shaped to match your logo precisely, allowing for endless design possibilities.
- LED Illumination: Logo boxes use energy-efficient LED bulbs, ensuring vibrant illumination day and night.
- Mounting Versatility: Unlike light boxes, logo boxes use trim caps and screws for mounting, providing a secure and sleek finish.
Specifications
Contour Logos and Logo Boxes Offerings
Available in a variety colors and with the option of painting. Custom coil is available at most depths for large quantity orders.
Our standard front acrylic is 3/16”. We have ⅛” available for smaller sizes and interior signs, and 3/16″ impact modified acrylic for larger signs needing higher durability.
Standard 1” trim caps are available in several colors (see our color charts), but 2” is also available in black, red, and white.
We utilize 3M 3630 vinyl for it’s high quality and consistency, available in several colors. We also can provide high quality 3M digital prints.
Backplates are routed and contoured based on electronic file to ensure accuracy and integrity with mounting pattern, and can be custom painted. All jobs come with 1/4″ 20 zinc coated threaded rod and rivnuts.
We can produce high quality custom painted raceways, extruded raceways, and wireways of various sizes, that also works well with backplates and contour logos.
Standoffs are usually between 1/2 – 2″, but can be customized, as well as can be painted to match façade and provide a finished product housing for threaded rods.
We utilize high quality Principle LEDs, available in different colors, as well as RGBw’s, allowing for a unique and customizable look to your channel letter signs.
We are U.L. 48 Certified. All signage and material are built to this set of regulations. In certain areas local and NEC codes may supersede U.L. and we will need to be notified of those differences.
Used in signs with halo lit back lighting, we can provide either a clear or a white (diffused) polycarb backer. Colored LED’s or applying 3M vinyl can also create unique colored halo effect. Baffles are also available with 5″ returns.
Minimum sizes range from 6”-8” inches depending on the complexity. Due to shipping constraints and integrity of the product, we can only do a single letter or logo up to 25’ in size.
DSW can color match and paint with most major brands including Matthews, Pantone, Benjamin Moore, and Sherwin Williams, as well as build other sign customizations.
How They're Made
Ensuring the Quality of Channel Letter Logo Boxes
To build contour logos, we create the overall shape outline and affix with either a colored vinyl application or a digital print for complete customization of a company logo. We make channel letter contour logo boxes up to 25 square feet, because the quality deteriorates above that size. Logos larger than 25 square feet should be made with extrusions or flexible faces, of which DSW does not manufacture.
